SK200-8HD SK210-9 Swing Gear Reduction Unit YN32W00025F1 SK210-9 SWING GEARBOX

Availability:

Quantity:



Inquire Add to Basket

Product Description

PRODUCT PARAMETERS

Part name	SK210-9 swing gearbox
Equipment	Apply to Kobelco EXCAVATOR
Part no.	YN32W00025F1
NO.1 sun gear spline teeth	19 splines
Swing pinion shaft teeth	13T
Item condition	New
Logo	LB
Gross weight	160kg
MOQ	1 pc

Product Descriptio

SK200超8(3) SK200超8(4) SK200超8(2)

Parts on group (SK210-9) - ACERA MARK 9 EXCAVATOR - TIER 4, ASN YQ13U5200 - (10/2012 -) (1/03-12/13):

Pos.	Part No	Qty	Parts name	Comments
1.	11124834	[13]	BOLT,Hex, M20 x 55mm, Cl 10.9	LEC M20 X 55 FULL 10.9 DAC
2.	87643225	[2]	PLUG	SM 10.0mm Slotted Plastic, (YN64H01391D1) Superseded by part number: YN64H01391D1
3.	87369427	[1]	LEVEL GAUGE	SM 385.5mm Long (15-11/64 in), (YN32W01101D1) Superseded by part number: YN32W01101D1
4.	YN32W01114D4	[1]	RIGID TUBE	SM 262mm Long (10-5/16 in)
5.	84189984	[1]	RIGID TUBE,20.80 mm ID x 27.20 mm OD x 250 mm L	SM DIA 27.2 Superseded by part number: YN32W01122D1
6.	87369430	[1]	PLUG	SM Cap, 3/4" PT, (ZE91T12000) Superseded by part number: ZE91T12000
7.	YN15V00054F1	[1]	HYDRAULIC MOTOR	SM Swing Hydraulic Motor Assy
7-1.	YN15V00055F1	[1]	HYDRAULIC MOTOR	SM Assy
7-2.	YN32W00025F1	[1]	GEAR REDUCTION UNIT	SM Swing Gear Reduction Unit

Parts on group (SK210-9) - ACERA MARK 9 EXCAVATOR - TIER 4, ASN YQ13U5200 - (10/2012 -) (1/03-12/13):

Pos.	Part No	Qty	Parts name	Comments
1.	YN32W01125P1	[1]	GEAR	SM Shaft
2.	YN32W01136P1	[1]	GEAR	SM
3.	YN32W01135P1	[3]	GEAR	SM Pinion
4.	YN32W01126P1	[1]	GEAR	SM
5.	YN32W01143P1	[4]	GEAR	SM
6.	YN32W01127P1	[1]	GEAR	SM Ring
7.	YN32W01123F1	[1]	SPIDER	KOB Gear, Incl 7-1 - 7-2
7-1.	NSS	[1]	NOT SOLD SEPARAT	CON Spider, Incl in 7
7-2.	NSS	[3]	NOT SOLD SEPARAT	CON Shaft, Incl in 7
8.	YN32W01130P1	[1]	PLANET CARRIER	SM
9.	YN32W01131P1	[4]	SHAFT	SM
10.	YN32W01030P1	[1]	SPHERICAL BEARING	KOB Superseded by part number: 25Z804D18
11.	YN32W01029P1	[1]	SPHERICAL BEARING	KOB Superseded by part number: R25P0047D9
12.	YN32W01060P1	[1]	OIL SEAL	SM
13.	YN32W01132P1	[1]	BOX	SM
14.	YN32W01026P1	[3]	THRUST WASHER	KOB
15.	YN32W01028P1	[3]	THRUST WASHER	KOB
16.	YN32W01022P1	[102]	ROLLER	KOB
17.	YN32W01072P1	[4]	NEEDLE BEARING	SM
18.	YN32W01063P1	[8]	WASHER	SM
19.	11068370	[1]	SNAP RING	MKT Retaining, ID 32.20 x OD 35 x Th 1.6mm Superseded by part number: 11068375
20.	ZR16X09000	[1]	RING	KOB Retaining, ID 84.50 x OD 108 x 3.0mm
21.	YN32W01133P1	[1]	SLEEVE	SM
22.	72210023	[4]	PIN	SM Roll Superseded by part number: ZP26D08025
23.	72210021	[11]	SCREW,Hex Socket Head, M14 x 130mm	SM Screw M14x2.0x135mm, (ZS23C14130) Superseded by part number: ZS23C14130
24.	PV02B01073DB	[2]	CAP	KOB 18.4mm Plastic
25.	YN32W01080D5	[1]	RIGID TUBE	SM 1/2" PT x 112mm Long
26.	ZG31U08000	[1]	HYD CONNECTOR	SM Elbow, 90° -- 1/2" PT
27.	72210000	[1]	PLUG	SM 1/2" PT, (ZE82T08000) Superseded by part number: ZE82T08000
28.	72211282	[3]	SNAP RING	SM Retaining, ID 37 x OD 40 x Th 1.8mm, (ZR16X04000) Superseded by part number: ZR16X04000
29.	YN32W01081P1	[1]	OIL SEAL	SM
30.	72283072	[1]	LUBE NIPPLE,67 Degree x 1/8" PT	IMO 67° x 1/8" PT, (ZG91V02000) Superseded by part number: ZG91V02000
31.	72210250	[1]	PLUG	IMO 1/8"PT, (ZE82T02000) Superseded by part number: ZE82T02000
