EC240 EC250 SWING REDUCER VOE14566202 VOE14724042 EC240 SWING GEARBOX

Availability:
Quantity:
Inquire Add to Basket

PRODUCT PARAMETERS
Part name
 EC240 EC250 Swing gearbox
Equipment Apply to VOLVO EXCAVATOR
Part no. VOE14566202 VOE14724042
NO.1 sun gear spline teeth 23 splines
Swing pinion shaft teeth 15T
Item condition New
Logo LB
Gross weight 325 KG
MOQ 1 pc


Product Description

EC240(4)EC240

Parts on group Swing gearbox:

EC240

Pos. Part No Qty Parts name Comments

  VOE14566202   [1]   Swing gearbox

  VOE14566202
  Swing gearbox   S/N -231281, -245014, -270803, -280131

  VOE14724042
  Swing gearbox   S/N 231282-, 245015-, 270804-, 280132-
1.   VOE14566206   [1]   Case
2.   VOE14552874   [1]   Ring
3.   VOE14566204   [1]   Collar
4.   VOE14566203   [1]   Shaft
5.   VOE14566205   [1]   Cover
6.   VOE14566209   [1]   Gear
7.   VOE947324   [16]   Hex. socket screw
8.   VOE984088   [12]   Hex. socket screw
9.   VOE14552875   [1]   Roller bearing
10.   SA9415-43012   [1]   Plug
11.   VOE914167   [1]   Lubricating nipple
12.   VOE14566207   [1]   Seal
13.   VOE14566208   [1]   Roller bearing
14.   VOE914492   [1]   Snap ring
15.   SA7118-30380   [1]   Thrust ring
16.   VOE14566216   [1]   Gear
17.   VOE14880960   [1]   Retaining ring
18.   VOE14566222   [1]   Gear
19.   VOE14547278   [1]   Thrust washer
20.   VOE14540733   [1]   Pipe
21.   VOE14566210   [1]   Planet carrier
22.   VOE14566211   [1]   Planet carrier
23.   VOE14566215   [4]   Pin
24.   VOE14566212   [4]   Gear
25.   VOE14566213   [4]   Bushing
26.   VOE14556491   [8]   Washer
27.   SA9325-06012   [4]   Spring pin
28.   VOE14566217   [1]   Planet carrier
29.   VOE14566218   [1]   Planet carrier
30.   VOE14566219   [3]   Gear
31.   VOE14566220   [3]   Bearing
32.   VOE14566221   [3]   Pin
33.   SA9325-06012   [3]   Spring pin
34.   VOE14556491   [6]   Washer
35.   VOE950677   [2]   Pin
36.   VOE949329   [1]   Gasket
37.   VOE14722461   [1]   Draining valve
