CAT 374F 374D Swing gearbox 378-9543 378-9544 3789543 3789544 CAT 374 swing gearbox

Availability:
Quantity:
Inquire Add to Basket

PRODUCT PARAMETERS
Part name
 CAT 374 Swing gearbox
Equipment Apply to CAT EXCAVATOR
Part no. 378-9543 378-9544
NO.1 sun gear spline teeth 13 splines
Swing pinion shaft teeth 12T
Item condition New
Logo LB
Gross weight --
MOQ 1 pc


Product Description

E374FE374F(3)E374F(4)E374F

378-9543: DRIVE GP-SWING
Pos. Part No Qty Parts name
1 7Y-0225 [3] SHAFT-PLANETARY
2 094-0574 [1] RING-RETAINING
3 094-0611 [6] WASHER (47.3X76X1-MM THK)
4 110-7053 [3] GEAR-PLANETARY (23-TEETH)
5 136-2889 [1] GEAR-SUN (23-TEETH)
6 136-2891 [1] CARRIER-PLANETARY
7 136-2893 [1] SPACER-SPECIAL
8 136-2894 [1] HOUSING
9 136-2896 [1] GEAR-RING (70-TEETH)
10 136-2897 [1] GEAR-SUN (22-TEETH)
11 136-2898 [8] WASHER (58.3X89X1-MM THK)
12 136-2899 [4] SHAFT-PLANETARY
13 136-2901 [4] GEAR-PLANETARY (23-TEETH)
14 136-2941 [1] CAGE
15 227-6221 [1] BREATHER AS (SWING DRIVE)

4H-6112 [1] BREATHER (SWING DRIVE)

227-6215 [1] BOSS (1/4-18-THD)

267-6785 [1] PIPE
16 267-6914 [1] SHAFT-PINION
17 296-6229 [1] CARRIER-PLANETARY
18 367-8323 [1] PIPE-GAUGE
19 367-8324 [1] GAUGE-OIL LEVEL
20 367-8325 [1] COVER-HOUSING
21 093-1730 [1] RING-RETAINING
22 093-1731 [1] RING-RETAINING
23 509-6676 [3] PIN-SPRING
24 096-2653 [1] RING-RETAINING
25 510-1989 [4] PIN-SPRING
26 135-9044 [2] SEAL-LIP TYPE
27 136-2904 [1] BEARING
28 136-2940 [1] BEARING
29 136-2942 [1] SEAL-O-RING
30 297-6841 [8] BEARING-ROLLER
31 3K-0360 [1] SEAL-O-RING
32 6V-7238 [1] VALVE-SHUTOFF (HYDRAULIC OIL)
33 453-2850 M [16] BOLT (M20X2.5X200-MM)
34 7Y-0252 [3] BEARING AS-ROLLER
35 7Y-0595 [2] SPACER (58X79.6X6-MM THK)
36 451-2176 [16] WASHER-HARD (22X35X3.5-MM THK)
37 453-3447 M [10] BOLT (M12X1.75X40-MM)
38 451-2182 [10] WASHER-HARD (13.5X25.5X3-MM THK)
